Table 5: SRX100 Services Gateway Front Panel LEDs (continued)
UsageDescriptionComponentNumber
The HA LED can be
used to determine if
chassis clustering is
enabled on the device.
The HA LED has the
following indicator
colors:
•
Solid green
indicates that all
chassis clustering
links are available.
•
Solid red indicates
that the chassis
clustering links are
not working as
expected.
•
Solid amber
indicates that some
chassis clustering
links are not
working as
expected.
•
Off indicates that
chassis clustering is
not enabled.
HA LED3
The Status LED can
be used to determine
whether the device is
starting up, is
functioning normally,
or has failed.
The Status LED has
the following indicator
colors:
•
Solid green
indicates that the
device is
functioning
normally.
•
Solid amber
indicates that the
device is starting
up.
•
Solid red indicates
that an error is
detected in the
device.
Status LED4
SRX100 Services Gateway Ethernet Port LEDs
On the SRX100 Services Gateway, each Fast Ethernet port has one functional LED on
the left side that indicates Link and Activity. In Figure 2 on page 10, this LED is marked as
1.
9Copyright © 2015, Juniper Networks, Inc.
Chapter 2: Hardware Component Overview
