CHAPTER 13
Providing Power to the SRX100 Services
Gateway
•
Connecting the SRX100 Services Gateway to the Power Supply on page 65
•
Powering On and Powering Off the SRX100 Services Gateway on page 66
Connecting the SRX100 Services Gateway to the Power Supply
To connect the device to the power supply:
CAUTION: Before connecting the device to the power supply, attach an ESD
strap to an ESD point and place the other end of the strap around your bare
wrist.
1. Plug the DC connector end of the power cable into the power connector on the back
of the device (see Figure 14 on page 65).
2. Plug the AC adapter end of the power cable into an AC power outlet.
Figure 14: Connecting the Services Gateway to the Power Supply
NOTE: The device must be connected to earth ground during normal
operation. The protective earthing terminal on the rear of the chassis is
provided to connect the device to ground.
65Copyright © 2015, Juniper Networks, Inc.
