General Site Guidelines for Installing the SRX100 Services Gateway
Keep the following precautions in mind to help you plan an acceptable operating
environment for your SRX100 Services Gateway and avoid environmentally caused
equipment failures:
•
For the operating temperature of the services gateway to be optimal, the airflow around
the chassis must be unrestricted. Allow sufficient clearance between the front and
back of the chassis and adjacent equipment. Ensure that there is adequate circulation
in the installation location.
•
Follow the ESD procedures to avoid damaging equipment. Static discharge can cause
components to fail completely or intermittently over time.
NOTE: The SRX100 Services Gateway does not include a fan and does not
generate any acoustic noise.
Related
Documentation
SRX100 Services Gateway Safety Requirements, Warnings, and Guidelines on page 121•
• SRX100 Services Gateway Cabinet Requirements on page 25
• SRX100 Services Gateway Rack Requirements on page 26
• Clearance Requirements for Airflow and Hardware Maintenance of the SRX100 Services
Gateway on page 27
SRX100 Services Gateway Specifications
The SRX100 Services Gateway chassis is a rigid sheet metal structure that houses all
the other hardware components (see Figure 5 on page 25).
Table 11 on page 24 provides information on the physical specifications of the device.
Table 11: SRX100 Services Gateway Specifications
ValueSpecification
1.38 in. (35 mm)Chassis height
8.5 in. (216 mm)Chassis width
5.79 in. (147 mm)Chassis depth
1.86 lb (844 g)Chassis weight
•
SRX100 Services Gateway Low Memory model: 10 watts
•
SRX100 Services Gateway High Memory model: 10 watts
Average power consumption
