KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
121
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
-
RW
Mode
-
0
1
0
Basic
OFF
0
-
-
-
-
-
-
Every run
1
Table 18. LE07 Rotor detection mode settings
Setting
Description
NUM
Off
The function is turned off.
0
NOP
A single pole position learned before each run is
performed. Encoder 1 Pole Position LE06 will
update at the beginning of each run.
1
Power on
A single pole position learned after power on.
2
NOP + Power on
After power on, a single pole position learned be-
fore each run is performed. Encoder 1 Pole Posi-
tion LE06 will update at the beginning of each run.
3
After reset
A single pole position learned after reset.
4
NOP + After reset
After reset, a single pole position learned before
each run is performed. Encoder 1 Pole Position
LE06 will update at the beginning of each run.
5
Power on + After reset
A single pole position learned after power on and
reset.
6
NOP + Power on + After
reset
After power on and reset, a single pole position
learned before each run is performed. Encoder 1
Pole Position LE06 will update at the beginning of
each run.
7
Default = Off (0)
LE08 Encoder Scaling
For encoders whose pulses per revolution exceeds that accepted by the 
interface, encoder scaling can be enabled.
 Refer to the example below and LE09 Encoder 1 Numerator and LE10 Encoder
1 Denominator for further details.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Ratio
-
0
2
-
-
0
Basic
OFF
0
-
-
-
-
-
-
Reserved
1
LE2 x LE9 / LE10
2
