KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
87
8.3 Input Parameters (LI)
Only PNP (sourcing, +24VDC = ON) inputs are supported. NPN (sinking, 0VDC =
ON) inputs are not supported. If NPN input control is desired a PNP/NPN
converter may be used.
LI02 Digital Input Filter
This parameter controls a digital noise filter which can be used to mask relay bounce or
other unwanted momentary signals. This filter applies to all digital inputs except the STO
Inputs. The STO Inputs are processed immediately.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
10
100
ms
-
20
Basic
LI03 Speed Input Decoding
When the control type US04 is set as digital (0) or binary (1) speed selection, the logic
table to which selected speed for a digital input combination must be determined.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
28
-
-
0
Basic
Table 11. LI03 Speed input decoding settings
Settings
NUM
US04 = Digital Speed Selection
B(Level - Correction - Inspection) + D(Level - Correct. - High - Inspect.)
0
B(Level - Correction - Inspection) + D(Level - High - Inspect. - Interm.)
4
B(Level - Correction - Inspection) + D(Inspect. - Level - High - Interm.)
8
B(Level - Correction - Inspection) + D(Level - Int.2 - High - Inspect.)
12
D(Level - High - Inspection - Correction - Intermediate 1)
16
US04 = Binary Speed Selection
B(Level - Correction - Inspection) + D(Level - Correct. - High - In-spect.)
0
B(Inspection - Level - Correction) + D(Level - Correct. - High - In-spect.)
1
B(Level - Correction - High) + D(Level - Correct. - High - Inspect.)
2
Decode with LI16 + D(Level - Correct. - High - Inspect.)
3
Default = B(Level - Correction - Inspection) + D(Level - Correct. - High - Inspect.)(0)
B indicates US04 Control Type = Binary Speed Selection
D indicates US04 Control Type = Digital Speed Selection
