KEB F6 - Table 26. LX21 Unintended Motion Settings

Parameter Descriptions
182
© 2024 KEB America, Inc.
LX17 ETS Speed
Emergency Terminal Slowdown (ETS) Speed corresponding to input programmed as
ETS Speed (29).
This parameter sets the speed limit the elevator must be under once the ETS switch is
crossed. The ETS sensors, normally closed type, must be routed to an input on the drive.
If the input turns off and the car speed is still above this value, the drive will automatically
trigger an emergency terminal slowdown using LS48-49 ESD/ETS Deceleration and Jerk
rates.  Refer to the ETS input function under parameter LI04 Input 1 Function.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
9
-
m/s
0
Basic
0
1600
ft/min
-
0
LX18 Braking Resistance
The braking resistor value can be set which allows the drive to calculate the total energy
dissipated by the resistor. A running total of the dissipated energy is measured in kWHrs
and is stored in drive parameter DG42 Regenerative Energy, or Diagnostic Screen #8
Braking Energy.
This provides the equipment owner an estimation of potential energy savings from line
regeneration.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
2000
Ohm
-
0
Basic
LX21 Unintended Car Movement (UCM)
This parameter controls whether the unintended movement event will be triggered or
ignored.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Unintended Motion
-
0
1
-
-
1
Basic
OFF
0
-
-
-
-
-
-
On with Error
1
Table 26. LX21 Unintended motion settings
Setting
Description
NUM
Off
No function
0
On with
Error
If the motor moves by more than the value set in LX25 after a normal high
speed run (not inspection operation), the Unintended Movement event will
occur.
1
Default = Off (0)
