KEB F6 User Manual

Parameter Descriptions
242
© 2024 KEB America, Inc.
8.17 Analog I/O Parameters (LA)
8.17.1 Analog Output 1
Settings LA31-35 for Analog Output 1 correspond with terminal ANOUT1.
LA31 Analog Output 1 Function
The following options in the table below can be assigned to the analog output. Speeds
are scaled such that 10V = Motor rpm at contract speed. RPM means motor rpm.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
AnOut1 function
-
0
7
-
-
0
Basic
abs actual speed
0
-
-
-
-
-
-
abs command speed
1
reserved
2
reserved
3
output voltage
4
DC bus voltage
5
phase current
6
actual torque
7
Table 40. LA31 analog output 1 function settings
Setting
0...10V =
NUM
Absolute actual speed

0
Absolute command speed

1
Reserved
Reserved for future use
2
Reserved
Reserved for future use
3
Output voltage

4
DC bus voltage

5
Phase current

6
Actual Torque

7
Default (LA31) = Actual Speed (2)
Default (LA36) = Actual Torque (7)
Similar to the analog inputs, with parameters LA33-35, the corresponding analog
output signals can be adapted in X and Y direction as well as in the gain. The
input values correspond to pre-processed values internal to the drive, and the
output values would be the post-processed analog output voltage from the drive
output terminals.
