KEB F6 User Manual

Method of Control
54
© 2024 KEB America, Inc.
5.4.2 Control Word (16-bit)
The control word consists of serial inputs.
The raw inputs may be masked with parameter FB05 Control Word Mask.
Table 6. Control word settings
Bit
Function
0
Enable
1
Reset
2
Up
3
Down
4
Binary Speed Input 1 or Binary Position 1
5
Binary Speed Input 2 or Binary Position 2
6
Binary Speed Input 3 or Binary Position 3
7
Reserved or Binary Position 4
8
Reserved or Binary Position 5
9
Special Function 1
10
Special Function 2
11
Special Function 3
12
Special Function 4
13
Special Function 5
14
Special Function 6
15
Special Function 7
Bits 0  3: Basic control word bits consisting of:
• Enable
• Up
• Down
• Reset
Bits 4  8: Assignment of serial selected binary-coded inputs for either speed or
position.
Bits 9  15: Serial input selection of special functions. Serial and discrete digital inputs
are independent unless assigned the same function; therefore, it is possible to have up to
14 functions defined between both serial and digital inputs.
Serial and/or digital inputs assigned the same function will be OR activated.
The available functions are the same as those for discrete digital inputs, described further
under LI04.
