PDI Data (Target Position) is the FB34-37 parameter corresponding to target position,
depending on the telegram structure. If the FB17-20 PDI Map Assignments are set
according to the telegram structure, then they can be used to determine which
corresponding FB34-37 PDI Data is used as raw data from the controller for target
position.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-2147483647
2147483647
-
-
0
Basic
8.15.2 Operations on PDI
These parameters are used to mask or scale by multiplier or divide the raw data received
from FB34-37 before being processed in FB01-04.
FB05 Field Bus Control Word Mask
Bit mask ANDed with Field Bus Control Word.
FFFFh = No Mask, 0000h = Mask All.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Enable
-
0
65535
-
-
65535
Basic
0
0
-
-
-
-
-
-
EN
1
Reset
-
0
0
RST
2
Up
-
0
0
UP
4
Down
-
0
0
DWN
8
Bin Speed 1 or Bin Pos 1
-
0
0
BIN1
16
Bin Speed 2 or Bin Pos 2
-
0
0
BIN2
32
Bin Speed 3 or Bin Pos 3
-
0
0
BIN3
64
Reserved or Bin Pos 4
-
0
0
BIN4
128
Reserved or Bin Pos 5
-
0
0
BIN5
256
Fb Special Function 1
-
0
0
SF1
512
Fb Special Function 2
-
0
0
SF2
1024
Fb Special Function 3
-

KEB F6 Specifications

General

Category	Inverter
Protection Class	IP20
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Series	F6
Output Frequency	0 Hz to 600 Hz
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
Control Modes	Sensorless vector control
Storage Temperature	-25°C to +70°C
