Parameter Descriptions
224
© 2024 KEB America, Inc.
0
0
SF4
4096
Fb Special Function 5
-
0
0
SF5
8192
Fb Special Function 6
-
0
0
SF6
16384
Fb Special Function 7
-
0
0
SF7
32768
Reset All Inputs
-
none
0
FB02 Field Bus Speed
Read-only display of processed field bus speed command, where 1 = 0.1 FPM.
FB02 =
PDI Data (Speed) x FB06 Speed Scale Multiplier
2^FB07 Speed Scale Shift Right
PDI Data (Speed) is the FB34-37 parameter corresponding to speed, depending on the
telegram structure. If the FB17-20 PDI Map Assignments are set according to the
telegram structure, then they can be used to determine which corresponding FB34-37
PDI Data is used as raw data from the controller for speed.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-32767
32767
-
-
0
Basic
FB03 Field Bus Pre-torque
Read-only display of pre-torque, where 1 = 1%. When in serial control mode if LC01 = 4,
FB03 is written to LC34 Digital Pre-torque at beginning of the run.
FB03 = PDI Data (Pre-torque)
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-100
100
%
-
0
Basic
FB04 Field Bus Target Position
Read-only display of processed field bus target position, where 1 = 1 count or 1 = 1/10
th
inch.
FB04 =
PDI Data (Target Position) x FB08 Position Scale Multiplier
2^FB09 Position Scale Shift Right
