Parameter Descriptions
124
© 2024 KEB America, Inc.
LE15 PT1 Time Encoder 1
Low pass filter on speed of the measured speed value.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
255
ms
-
0
Basic
LE16 SSI Data Format
Sets the data format of the SSI transmission between encoder and inverter.
This parameter is only relevant when the encoder type is SSI, and SSI feedback
interface is used (LE01 = SSI-SIN/COS).
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
SSI PFB Mode
-
0
31
-
-
0
Basic
PFB Off
0
-
-
-
-
-
-
PFB at start of data
1
PFB at end of data
2
reserved
3
Even Parity Check
-
No Parity Check
0
Even Parity Check
4
Data Format
-
Fir Tree
0
Serial Right Aligned
8
SSI Data Code
-
Binary
0
Gray
16
LE17 Single Turn Resolution
Sets the resolution of the data of the SSI transmission.
This parameter is only relevant for digital encoders (SSI, Endat 2.2, BiSS).
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
40
-
-
0
Basic
