Parameter Descriptions

173

LC44 Torque Command Filter

Provides a low pass filter on the torque command signal before it is fed into the current

control. Lower values can be used to eliminate audible harmonic sounds which may be

heard in the motor.

Motor Type

Setting Options

NUM

Range

Units

Default

Pass

Level

Ind.

Min.

Max.

Imp.

Met.

Torque Command Filter

Basic

OFF

2000 Hz

1000 Hz

500 Hz

250 Hz

125 Hz

63 Hz

31 Hz
