KEB F6 User Manual

Parameter Descriptions
230
© 2024 KEB America, Inc.
FB17 PDI1 Map Assignment
Field bus parameter hex address, set, size, and bytes corresponding to Process Data
Input 1.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
FB PDI MAPPING
-
0
4
-
-
1
Basic
FB01 Control Word
1
-
-
-
-
-
-
FB02 Speed
2
FB03 Pretorque
3
FB04 Target Position
4
off
0
FB18 PDI2 Map Assignment
Field bus parameter hex address, set, size, and bytes corresponding to Process Data
Input 2.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
FB PDI MAPPING
-
0
4
2
Basic
FB01 Control Word
1
-
-
-
-
-
-
FB02 Speed
2
FB03 Pretorque
3
FB04 Target Position
4
off
0
FB19 PDI3 Map Assignment
Field bus parameter hex address, set, size, and bytes corresponding to Process Data
Input 3.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
FB PDI MAPPING
-
0
4
3
Basic
FB01 Control Word
1
-
-
-
-
-
-
FB02 Speed
2
FB03 Pretorque
3
FB04 Target Position
4
off
0
FB20 PDI4 Map Assignment
Field bus parameter hex address, set, size, and bytes corresponding to Process Data
Input 4.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
FB PDI MAPPING
-
0
4
4
Basic
FB01 Control Word
1
-
-
-
-
-
-
FB02 Speed
2
FB03 Pretorque
3
FB04 Target Position
4
off
0

KEB F6 Specifications

General

Category	Inverter
Protection Class	IP20
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Series	F6
Output Frequency	0 Hz to 600 Hz
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
Control Modes	Sensorless vector control
Storage Temperature	-25°C to +70°C
