KEB F6 User Manual

Combivis
© 2024 KEB America, Inc.
251
9.3.4.2 Setting Up the Scope on Combivis (Online)
Live/Online scoping means the scope is started by the user and continues until ended by
the user.
1. Turn on drive if drive is not already on.
2. Open Combivis 6 software.
( Refer to Figure 34, pg. 247)
3. Select SCAN FOR KEB DEVICES under Start Up/Configuration.
( Refer to Figure 35, pg. 247)
4. The KEB Device Scan pop-up menu will appear. Ensure all COM interfaces are
selected and select START SEARCH.
( Refer to Figure 36, pg. 248)
5. Once search is complete, nodes will appear under Found Devices. Ensure all
nodes are selected and select ADD SELECTED DEVICES.
( Refer to Figure 37, pg. 249)

KEB F6 Specifications

General

Category	Inverter
Protection Class	IP20
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Series	F6
Output Frequency	0 Hz to 600 Hz
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
Control Modes	Sensorless vector control
Storage Temperature	-25°C to +70°C
