Parameter Descriptions
© 2024 KEB America, Inc.
99
Value
Speeds
A
Intermediate 1
C
Intermediate 2
E
Intermediate 3
The parameter is 7 digits, populated one digit at a time with the above values to create
the decoding. The first, right-most digit corresponds to binary 001 and the seventh, left-
most digit corresponds to binary 111 where I8>...>I1. Zero speed is fixed with binary 000.
I4
I3
I2
Digit
0
0
0
-
0
0
1
1 (Right-most)
0
1
0
2
0
1
1
3
1
0
0
4
1
0
1
5
1
1
0
6
1
1
1
7 (Left-most)
For example, the binary input logic table corresponding to the default setting of LI03
Speed Input Decoding = B(Level - Correction - Inspection), NUM = 0, would be LI16 =
ECA8642 (note the order of the inputs).
Binary speed
selection
Parameter
Control inputs
LI16
Value
I2
I3
I4
S ZERO
-
x
x
x
-
S LEVELING
LS01
1
0
0
2
S HIGH
LS02
0
0
1
4
S INSPECTION
LS03
1
1
0
6
S CORRECTION
LS04
0
1
0
8
S INTERMEDIATE 1
LS05
1
0
1
A
S INTERMEDIATE 2
LS06
0
1
1
C
S INTERMEDIATE 3
LS07
1
1
1
E
LI20 Brake Switch Function
Sets the response to a Brake Switch Failure fault when an input is assigned as Brake
Release Confirmation.
This parameter controls the function of the brake switch inputs on X1C. One or two inputs
can be used to monitor the status of the brake switch, or an auxiliary contact on the brake
contactor. In addition, this parameter determines the method required to reset the fault.
The brake switch inputs are normally active inputs, meaning the input is normally active
during the idle state. In this way, the presence of the signal is confirmed prior to the start
of operation.
