Keithley 2002 User Manual

Keithley Instruments, Inc.
28775 Aurora Road
Cleveland, Ohio 44139
1-888-KEITHLEY
www.keithley.com
Specifications are subject to change without notice.
Page 6 of 14 SPEC-2002 Rev. H / February 2009
Model 2002
Multimeter Specifications
Settling Characteristics:
Normal Mode (rms, avg.): <300ms to 1% of step change
<450ms to 0.1% of step change
<500ms to 0.01% of step change
Low Frequency Mode (rms) <5s to 0.1% of final value
Common Mode Rejection: For 1k imbalance in either lead: >60dB for line frequency ±0.1%.
Maximum Volt·Hz Product: 2 x 10
7
V·Hz (for inputs above 20V).
Autoranging: Autoranges up at 105% of range, down at 10% of range.
OHMS
TWO-WIRE AND FOUR-WIRE OHMS
Range
Full
Scale Resolution
Current
Source
29
Open
Circuit
12
Maximum
HI Lead
Resistance
30
Maximum
LO Lead
Resistance
30
Maximum
Offset
Compensation
31
20  21.0000000 100 n 7.2 mA 5 V 50  10  ±0.2 V
200  210.000000 1 µ 960 µA 5 V 200  100  ±0.2 V
2 k 2100.00000 10 µ 960 µA 5 V 200  150  –0.2 V to +2 V
20 k 21.0000000 100 µ 96 µA 5 V 1.5 k 1.5 k –0.2 V to +2 V
200 k 210.000000 1 m 9.6 µA 5 V 1.5 k 1.5 k
2 M 2.10000000 10 m 1.9 µA 6 V 1.5 k 1.5 k
20 M
32
21.0000000 100 m 1.4 µA
33
14 V
200 M
32
210.000000 1  1.4 µA
33
14 V
1 G
32
1.05000000 10  1.4 µA
33
14 V
KEITHLEY FACTORY CALIBRATION UNCERTAINTY
Range ppm of reading
20  29.5
200  7.7
2 k 6.4
20 k 7.8
200 k 7.3
2 M 14.9
20 M 14.9
200 M 14.9
1 G 14.9
Factory calibration uncertainty represents traceability to NIST. This uncertainty is added to relative accuracy specifications to obtain absolute
accuracies.
The 20 - 2M range uncertainties are equal to the uncertainty of the respective calibration sources.
The 20M, 200M, and 1G range uncertainties are equal to the uncertainty of the 2M calibration source.
ENHANCED ACCURACY
34
10PLC, Offset comp. on, DFILT 10
Relative Accuracy
± (ppm of reading + ppm of range)
Range Transfer
5
24 Hours
35
90 Days
7
1 Year
7
2 Years
7
TemperatureCoefficient
± (ppm of reading + ppm of range) / °C
Outside TCAL ±5°C
20 2.5 + 3 5 + 4.5 15 + 6 17 + 6 20 + 6 2.5 + 0.7
200 2.5 + 2 5 + 3 15 + 4 17 + 4 20 + 4 2.5 + 0.5
2 k 1.3 + 0.2 2.5 + 0.3 7 + 0.4 9 + 0.4 11 + 0.4 0.8 + 0.05
20 k 1.3 + 0.2 2.5 + 0.3 7 + 0.4 9 + 0.4 11 + 0.4 0.8 + 0.05
200 k 2.5 + 0.4 5.5 + 0.5 29 + 0.8 35 + 0.9 40 + 1 3.5 + 0.18
2 M 5 + 0.2 12 + 0.3 53 + 0.5 65 + 0.5 75 + 0.5 7 + 0.1
20 M
32
15 + 0.1 50 + 0.2 175 + 0.6 250 + 0.6 300 + 0.6 20 + 0.1
200 M
32
50 + 0.5 150 + 1 500 + 3 550 + 3 600 + 3 80 + 0.5
1 G
32
250 + 2.5 750 + 5 2000 + 15 2050 + 15 2100 + 15 400 + 2.5
29
Current source has an absolute accuracy of ±5%.
30
Refers to source lead resistance. Sense lead resistance is limited only by noise considerations. For best results, it is suggested that it be limited to 1.5k.
31
Offset compensation voltage plus source current times measured resistance must be less than source current times resistance range selected.
32
For 2-wire mode.
33
Current source is paralleled with a 10M resistance.
34
Specifications are for 10 power line cycles, 10-reading repeat digital filter, synchronous autozero, autorange off, 4-wire mode, offset compensation on (for 20 to
20k ranges), except as noted.
35
For T
CAL
±1°C, following 4-hour warm-up. T
CAL
is ambient temperature at calibration (23°C at the factory).

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
