Model 2002
Multimeter Specifications
Physical Case Dimensions: 90mm high × 214mm wide × 369mm deep (3½ in. × 8½ in. × 14½ in.).
Working Dimensions: From front of case to rear including power cord and IEEE-488 connector: 15.0 inches.
Net Weight: <4.2kg (<9.2 lbs.).
Shipping Weight: <9.1kg (<20 lbs.).
Standards EMI/RFI: Conforms to VDE 0871B (per Vfg 1046/1984), IEC 801-2. Meets FCC part 15 Class B, CISPR-22 (EN55022).
Safety: Conforms to IEC348, CAN/CSA-C22.2. No. 231, MIL-T-28800E
1
. Designed to UL1244.
Accessories Supplied The unit is shipped with line cord, high performance modular test leads, operator’s manual, option slot cover, and
full calibration data.
EXTENDED MEMORY/NON-VOLATILE MEMORY OPTIONS
DATA STORAGE
Setup Storage
Model Size (Bytes) 4½-Digit
6½-Digit with
Time Stamp Type
Number Type
2002 8k 2,027 404 volatile 1 non-volatile
2002/MEM1 32k 6,909 1,381 non-volatile 5 non-volatile
2002/MEM2 128k 29,908 5,980 non-volatile 10 non-volatile
These are the minimum sizes to expect.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
