Keithley 2002 User Manual

HP3458A Emulation Mode
H-15
FAST
Same as NORM with the following exceptions:
DCV 10 OFORMAT DINT
DISP OFF TRIG AUTO
AZERO OFF
DIG: Not supported.
Default NORM
Description The PRESET command selects one of two preset instrument configurations, one for normal opera-
tion, and one for fast operation. The DIG preset configuration supported by the HP3458A is not sup-
ported by the Model 2002.
Example PRESET FAST Select fast configuration.
RANGE
Purpose To select the measurement range.
Format RANGE <max_input> ,<%_resolution>
Parameter <max_input> Manual range or AUTO (autorange)
<%_resolution> Ignored
Default AUTO
Query RANGE? Returns the present measurement range for the current function.
Description The RANGE command allows you to select a manual measurement range or autorange. (See paragraph
3.18 for range information specific to each function.) Specifying AUTO for the <max_input>
parameter enables autoranging, and the <%_resolution> parameter is ignored.
Example RANGE AUTO Select autorange.
RESET
Purpose To reset the Model 2002 to the power-on state.
Format RESET
Parameter None
Description The RESET command resets the multimeter to the power-on state without cycling power. Reset
effectively executes:

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
