Front Panel Operation
2-43
ARM
SOURCE
IMMEDIATE
EXTERNAL
MANUAL
GPIB
TRIGLINK
RT-CLOCK
HOLD
COUNT
INFINITE
ENTER-ARM-COUNT
CONTROL
SOURCE
ACCEPTOR
Arm layer menu:
Select arm source:
Use to arm meter immediately and pass operation into the scan layer.
Use external triggers to arm meter.
Use TRIG key to arm meter.
Use bus triggers to arm meter.
Use Trigger Link triggers to arm meter. Enter Trigger Link lines.
Use clock to arm meter. Enter time and date.
Use to hold up the measurement in the arm layer.
Define number of times to arm meter:
Continuously re-arm meter.
User defined count value (1-99999).
Select trigger control mode:
Enable Source Bypass.
Disable Source Bypass.
HALT Use to halt triggers. Press TRIG key to resume triggering.
Table 2-27
CONFIGURE TRIGGER menu structure (cont.)
Menu item Description
