Status register overview
You can use status register programming to determine the operating condition of the power supply at
any time. For example, you can program the power supply to generate an interrupt when an event
such as overtemperature protection occurs.
The Standard Event Register, Status Byte Register, Service Request Enable Register, and the output
queue perform standard GPIB functions as defined in the IEEE-488.2 Standard Digital Interface for
Programmable Instrumentation - Part 2: Codes, Formats, Protocols, and Common Commands. The
Operation Status Register and Questionable Status Register implement functions that are specific to
the Series 2230G.
The following table describes the status signals.
Status signals
Bit Signal Description
Operation Instrument Summary Register
0
CV
Constant voltage
1
CC
Constant current
2
CAL
The power supply is calculating the new calibration parameter
3
ON/OFF
The output of the power supply is ON or OFF
Operation Instrument Status Register
1
INST1
STATus:OPERation:INSTrument:ISUMmary1 is reported to INST1
2
INST2
STATus:OPERation:INSTrument:ISUMmary2 is reported to INST2
3
INST3
STATus:OPERation:INSTrument:ISUMmary3 is reported to INST3
Operation Status Register
1
ISUM
Summary of STAT:OPER:INST
Questionable Instrument Summary Register
0
CV
Constant voltage
1
CC
Constant current
Questionable Instrument Status Register
1
INST1
STATus:QUEStionable:INSTrument:ISUMmary1 is reported to INST1
2
INST2
STATus:QUEStionable:INSTrument:ISUMmary2 is reported to INST2
3
INST3
STATus:QUEStionable:INSTrument:ISUMmary3 is reported to INST3
Section 6
Status register
