Series 2230G
Triple-Channel Power Supplies User's Manual Section 4:
Introduction to SCPI
2230G-900-01 Rev. A / June 2018 4-3
The following figure illustrates SCPI message structure.
Figure 15: SCPI message structure
Command execution rules
The following are a few basic rules of SCPI command execution:
• Commands execute in the order that they are presented in the command message.
• An invalid command generates an error message and is not executed.
• Valid commands that precede an invalid command in a multiple command message are
executed.
• Valid commands that follow an invalid command in a multiple command message are ignored.
Case sensitivity
Common commands and SCPI commands are not case sensitive. You can use uppercase or
lowercase characters, as shown in the following examples:
*RST = *rst
:DATA? = :data?
:SYSTem:PRESet = :system:preset
