Section
2: Quick reference Series 2230G Triple-Channel Power Supplies
User's Manual
2-2 2230G-900-01 Rev. A / June 2018
Number Description
1
Vacuum fluorescent display (VFD)
2
Navigation wheel
3
Output terminals
4
Up, down, left, and right arrow keys; Enter, Save, and Recall function keys
5
Numeric keypad and Esc key
6
Function keys: Channel SELECT (CH1, CH2, CH3), voltage setting (V-Set), current setting
(I-Set), Menu, and OUTPUT On/Off keys
7
Power On/Off switch
Rear-panel overview
All of the Series 2230G power supplies have the same rear panel. The rear panel is shown in the
figure below; descriptions of the numbered items follow the figure.
Figure 2: Series 2230G rear panel
Number Description
1 Vent
2
RS-232 communication interface
3
USB communication interface
4
GPIB communication interface
5
AC power input socket (including fuse)
6
Remote sense terminals and the output terminals
