Keithley 2230G-30-3 User Manual

In this section:
Welcome .................................................................................. 1-1
Products ................................................................................... 1-1
Extended warranty ................................................................... 1-2
Contact information .................................................................. 1-2
Key features ............................................................................. 1-2
Accessories .............................................................................. 1-3
Available services .................................................................... 1-4
General ratings ......................................................................... 1-4
Wire specifications ................................................................... 1-4
Welcome
Thank you for choosing a Keithley Instruments product. The Series 2230G Triple-Channel Power
Supplies (Models 2230G-30-3, 2230G-30-6, and 2230G-60-3) provide output power up to 195 W and
375 W. Each power supply has three isolated power channels, allowing you to power circuits with
different references or polarities.
The Series 2230G supports remote sensing and has rear-panel connections to make automated test
more convenient. Built in RS-232, USB, and GPIB interfaces allow multiple communication methods.
The Series 2230G power supplies cover a wide range of applications in a space-saving 2U half-rack
size.
Products
This manual contains information about the models listed in the following table.
Model Description
2230G-30-3
Triple-Channel Power Supplies, 2 channels: 30 V, 3 A, 1 channel:
5 V, 3 A, 195 W
2230G-30-6
Triple-Channel Power Supplies, 2 channels: 30 V, 6 A, 1 channel:
5 V, 3 A, 375 W
2230G-60-3
Triple-Channel Power Supplies, 2 channels: 60 V, 3 A, 1 channel:
5 V, 3 A, 375 W
Section 1
Introduction

Keithley 2230G-30-3 Specifications

General

Brand	Keithley
Model	2230G-30-3
Category	Power Supply
Language	English
