Keithley 2230G-30-3 User Manual

Series 2230G
Triple-Channel Power Supplies User's Manual Section 2:
Quick reference
2230G-900-01 Rev. A / June 2018 2-9
If you switch to the front-panel control, all remote commands sent through the USB interface will be
invalid. If you want to continue to use the remote commands, you need to send the SYSTem:REMote
command or restart the USB interface using the VISA software.
RS-232 interface
You can connect a computer to your Series 2230G RS-232 port using a cable with two COM
connectors.
Please ensure the computer and power supply have the same configuration for the following items:
• Baud rate: 4800, 9600, 19200, 38400, 57600, or 115200.You can enter the system menu to set
the baud rate.
• Data bit: 8
• Stop bit: 1
• Parity bit: (none, even, odd)
 none: 8 data bits that have no parity
 even: 8 data bits that have even parity
 odd: 8 data bits that have odd parity
For example:
Parity = None Start bit 8 data bits Stop bit
To use the RS-232 interface:
1. Make sure the connection from the Series 2230G to the computer is firmly inserted in the port.
2. Press the Menu key.
3. Use the arrow keys to select User settings.
4. Press Enter. The screen displays Output Recall.
5. Press the down arrow keys to select Communication Port.
6. Press Enter.
7. Use the arrow keys to select RS232.
8. Select the baud rate from the following options:
 4800
 9600
 19200
 38400
 57600
 115200
9. Select the parity from the following the options:
 None
 Even
 Odd
10. Press Enter to confirm your selection.
