In this section:
Introduction .............................................................................. 3-1
Front-panel operation ............................................................... 3-1
Menu description ...................................................................... 3-4
Basic settings ........................................................................... 3-5
Restore default settings ........................................................... 3-6
Enable or disable channels ...................................................... 3-7
Set the maximum voltage ......................................................... 3-7
Set the output timers ................................................................ 3-8
Set the key lock status ............................................................. 3-8
Track ........................................................................................ 3-9
Combine ................................................................................. 3-10
User settings .......................................................................... 3-15
System information ................................................................ 3-17
Overtemperature protection ................................................... 3-18
Use the rear-panel terminals .................................................. 3-18
Introduction
This section contains detailed descriptions of the functions and features of the Series 2230G power
supply.
Front-panel operation
After the power supply is powered on, the display will show the voltage and current settings of each
channel. When these settings are displayed, you can connect the DUT to the power supply and set
the parameters. Ensure that OUTPUT On/Off key is set to the Off state before connecting the DUT
and setting the parameters. After finishing the setup, set OUTPUT On/Off key to the On state and
start the measurement.
You can use the navigation wheel to increase or decrease a value or to scroll through the menus after
pressing the Menu key.
The display shows the operating status of each channel. When a channel operates in constant
voltage mode, the CV indicator is displayed. When it operates in the constant current mode, the CC
indicator is displayed.
To cancel an operation (V-set, I-set, Save, Recall, or Menu), press the Esc key.
If the front panel is locked with a password, enter the correct password after you press the function
keys (V-set, I-set, Save, Recall, or Menu); then you can change the settings.
