1: Introduction Series 2230G Triple-Channel Power Supplies
User's Manual
1-4 2230G-900-01 Rev. A / June 2018
Available services
For the most recent list of available services and accessories, upgrades, and options for your
instrument, visit tek.com/keithley
.
General ratings
The Series 2230G general ratings and connections are listed in the following table.
Category Specification
Power supply
2230G-30-3 AC power input level:
110 to 120 VAC: 99 VAC to 132 VAC
220 to 240 VAC:198 VAC to 264 VAC
50 Hz or 60 Hz
2230G-30-6/2230G-60-3 AC power input level:
120 VAC: 108 VAC to 132 VAC
220 to 240 VAC: 198 VAC to 264 VAC
50 Hz or 60 Hz
Maximum power consumption:
2230G-30-3: 700 VA
2230G-30-6, 2230G-60-3: 1000 VA
Maximum current: 10 A
Floating voltage
Up to 400 V (DC + peak AC) between protective earth (safety ground)
and any output terminal
Operating altitude
Maximum 2000 m (6562 ft ) above sea level
Environmental conditions
For indoor use only
Operating: 0 °C to 40 °C, full accuracy with maximum 80% relative
humidity at up to 40 °C, non-condensing
Storage: –20 °C to 70 °C, 10% to 85% relative humidity at up to
40 °C and 5% to 60% relative humidity above 40 °C up to 70 °C
Pollution degree: 2
Installation category:
II
Wire specifications
Refer to the table below for the maximum current allowed for the various gauges of copper wire.
AWG wire gauge 10 12 14 16 18 20 22 24 26 28
Maximum current (A)
40
25
20
13
10
7
5
3.5
2.5
1.7
The table above lists current carrying capacity of single wire at working temperature of 30 °C. The
values in this table conform with the American Wire Gauge (AWG) standard and are provided for
reference only.
