3-62 Keysight B1505A User’s Guide, Edition 12
Accessories
Table 3-9 HCSMU Source Setting Range for ON State
Table 3-10 HVSMU Voltage Measurement Range
Table 3-11 Current Measurement Range
Range
Setting value
a
a. Voltage actually applied to the device under test (DUT) is the setting
value minus the voltage drop of the switch.
Resolution Compliance
2 V 0 V to 2 V 2 V 20 mA to 1 A DC,
or 20 mA to 20 A
pulse
20 V 0 V to 20 V 20 V
40 V 0 V to 40 V 40 V 20 mA to 1 A DC
Range
a
a. Range depends on the HVSMU source setting for the device OFF state.
Measurement value Resolution
200 V 0 V to 200 V 200 V
500 V 0 V to 500 V 500 V
1500 V 0 V to 1500 V 1.5 mV
3000 V 0 V to 3000 V 3 mV
HCSMU HVSMU
Range
a
a. Range depends on the HCSMU source setting for the device ON state.
Resolution Range Resolution
100 mA 100 nA 10 mA 10 nA
1 A 1 A
20 A (pulse) 20 A
