Keysight B1505A User’s Guide, Edition 12 3-63
Accessories
Following tables are for the ON state static characteristics measurements. The
N1267A keeps switch ON status. HCSMU performs I-V measurement. HVSMU
applies 0 V with 1 A compliance and measures Vds or Vf. Id or If is given by the
total current measured by HCSMU and HVSMU.
Table 3-12 Source Setting Range for Id-Vds, If-Vf Measurement
Table 3-13 HVSMU Voltage Measurement Range for Id-Vds, If-Vf Measurement
Table 3-14 Current Measurement Range for Id-Vds, If-Vf Measurement
Offset error for the Id-Vds, If-Vf measurement is typical 1 A.
HCSMU source setting
HVSMU source
setting
Range Setting value Resolution Compliance
2 V 0 V to 2 V 2 V10 A to 1 A DC,
or 10 A to 20 A
pulse
0 V output with
1 A compliance
20 V 0 V to 20 V 20 V
40 V 0 V to 40 V 40 V 10 A to 1 A DC
Range Measurement value Resolution
200 V 0 V to 200 V 200 V
HCSMU HVSMU
Range Resolution Range Resolution
10 A 10 pA 1 A 10 nA
100 A 100 pA
1 mA 1 nA
10 mA 10 nA
100 mA 100 nA
1 A 1 A
20 A (pulse) 20 A
