8.7.1 :STATus:PRESet
Clears all status group event registers. Presets the status group enables PTR and
NTR registers as follows:
ENABle = 0x0000, PTR = 0xffff, NTR = 0x0000
8.7.2 Status Byte Register
The Status Byte summary register reports conditions from the other status registers.
Data that is waiting in the instrument’s output buffer is immediately reported on the
“Message Available” bit (bit 4) for example. Clearing an event register from one of the
other register groups will clear the corresponding bits in the Status Byte condition
register. Reading all messages from the output buffer, including any pending queries,
will clear the “Message Available” bit. To set the enable register mask and generate
an SRQ (service request), you must write a decimal value to the register using the
*SRE command.
Table 8-2: Status Byte Register
Bit Number
Decimal Value
Definition
0 Not used
1
Not Used. Returns “0”
1 Not used
2
Not Used. Returns “0”
2 Error Queue
4
One or more error are stored in the Error Queue
3 Questionable Data
8
One or more bits are set in the Questionable Data
Register (bits must be enabled)
4 Message Available
16
Data is available in the instrument’s output buffer
5 Standard Event
32
One or more bits are set in the Standard Event Register
6 Master Summary
64
One or more bits are set in the Status Byte Register
7 Operational Data
128
One or more bits set in the Operation Data Register (bits
must be enabled)
