8.7.6 Frequency Status Subsystem
The Frequency Status register contains the frequency conditions of the individual
channels.
The following SCPI commands and queries are supported:
:STATus:QUEStionable:FREQuency[:EVENt]?
:STATus:QUEStionable:FREQuency:CONDition?
:STATus:QUEStionable:FREQuency:ENABle[?]
:STATus:QUEStionable:FREQuency:NTRansition[?]
:STATus:QUEStionable:FREQuency:PTRansition[?]
Table 8-6: Frequency Status Register
Bit Number
Decimal Value
Definition
0 Frequency warning
1
Output 1 signal is invalid
1 Frequency warning
2
Output 2 signal is invalid
8.7.7 Sequence Status Subsystem
The Sequence Status register is used to indicate errors in the sequence table data
provided by the user. It contains the conditions of the individual channels.
The following SCPI commands and queries are supported:
:STATus:QUEStionable:SEQuence[:EVENt]?
:STATus:QUEStionable:SEQuence:CONDition?
:STATus:QUEStionable:SEQuence:ENABle[?]
:STATus:QUEStionable:SEQuence:NTRansition[?]
:STATus:QUEStionable:SEQuence:PTRansition[?]
Table 8-7: Sequence Status Register
Bit Number
Decimal Value
Definition
0 Sequence data error
1
Output 1 sequence has errors
1 Sequence data error
2
Output 2 sequence has errors
2 Linear-playtime error
4
Output 1 has a linear-playtime error
3 Linear-playtime error
8
Output 2 has a linear-playtime error
4 Streaming data error
16
Output 1 ran out of streaming data
5 Streaming data error
32
Output 2 ran out of streaming data
