Keysight M8190A - Output[1|2]:Dioffset[?] <Value>|Minimum|Maximum

General Programming 8
M8190A User’s Guide 231
8.13.5 :OUTPut[1|2]:DIOFfset[?] <value>|MINimum|MAXimum
Command
:OUTP:DIOF[?]
Long
:OUTPut:DIOFfset[?]
Parameters
<value>|MINimum|MAXimum
Parameter Suffix
None
Description
Differential Offset: The hardware can compensate for little offset differences between
the normal and complement output. “<value>” is the offset to the calibrated optimum
DAC value, so the minimum and maximum depend on the result of the calibration. of
Example
Command
:OUTP:DIOF MAX
Query
:OUTP:DIOF?
Table 8-13: Differential Offset
Value
Normal Output
Complement Output
< 0
Offset decreased
Offset increased
0
No offset
> 0
Offset increased
Offset decreased
Due to the use of DAC values, the granularity is 1. At the direct output (DAC) at 50Ω:
1 ≈ 1.526μV. At the DC output the resulting offset depends on the voltage settings.
