Introduction 1
M8190A User’s Guide 27
NRZ: DAC A sends value for whole sample period
DNRZ: DAC A and B send same value
Doublet: DAC A sends +Value, DAC B
sends –Value
RZ (not specified but available as over
programming): DAC A sends value, DAC B
fixed value
Figure 1-4: DAC Format Modes
t
V
DAC
B
DAC
A
t
V
DAC
B
DAC
A
t
V
DAC
B
DAC
A
t
V
DAC
B
DAC
A
