[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:STARt[:LEVel] <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:STARt[:LEVel]? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:STARt[:LEVel] <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:STARt[:LEVel]? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the initial current or voltage level after the exponential waveform ends for Arb sequence
steps.
Parameter Typical Return
Current: 0 - maximum|MIN|MAX, *RST MIN
Voltage: 0 - maximum|MIN|MAX, *RST MIN
The maximum value varies, depending on the currentor voltage
rating of the power module.
<start value>
Step 0 - 99, *RST 0 (none)
Programs a start level current: ARB:CURR:EXP:STAR 0,(@1)
Programs a start level voltage: ARB:VOLT:EXP:STAR 0,(@1)
Programs a start currentfor step 0: ARB:SEQ:STEP:CURR:EXP:STAR 0, 0,(@1)
[SOURce:]ARB:CURRent:EXPonential:STARt:TIMe <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:EXPonential:STARt:TIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:STARt:TIMe<value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:STARt:TIMe? [MIN|MAX,] (@<chanlist>)
Specifies the delay in seconds after the trigger is received, but before the exponential waveform
occurs. Referenced to t0 in the Exponential diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:STARt:TIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:STARt:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:STARt:TIMe<value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:STARt:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the delay in seconds after the trigger is received, but before the exponential waveform
occurs for Arb sequence steps.
Parameter Typical Return
0 – 262.144 | MIN | MAX, *RST 0 <start time>
Step 0 - 99, *RST 0 (none)
Programs a start time for the current Arb: ARB:CURR:EXP:STAR:TIM 1,(@1)
Programs a start time for the voltage Arb: ARB:VOLT:EXP:STAR:TIM 1,(@1)
Programs a start time for step 0: ARB:SEQ:STEP:CURR:EXP:STAR:TIM 1, 0,(@1)
Keysight N6705C Operating and Service Guide 239
7 SCPI Programming Reference
