[SOURce:]ARB:CURRent:EXPonential:TCONstant <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:EXPonential:TCONstant? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:TCONstant <value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:TCONstant? [MIN|MAX,] (@<chanlist>)
Specifies the time constant of the exponential curve. Referenced to tc in the Exponential diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:TCONstant <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:TCONstant ? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:TCONstant <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:TCONstant ? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the time constant of the exponential curve for Arb sequence steps.
Parameter Typical Return
0 – 262.144 | MIN | MAX, *RST 1 <time constant>
Step 0 - 99, *RST 0 (none)
Programs a timeconstant for the current Arb: ARB:CURR:EXP:TCON 5,(@1)
Programs a timeconstant for the voltage Arb: ARB:VOLT:EXP:TCON 5,(@1)
Programs a timeconstant for step 0: ARB:SEQ:STEP:CURR:EXP:TCON 5, 0,(@1)
[SOURce:]ARB:CURRent:EXPonential:TIMe <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:EXPonential:TIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:TIMe <value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:TIMe? [MIN|MAX,] (@<chanlist>)
Specifies the total time for the current or voltage to go from the starting level to the ending level in
seconds. Referenced to t1 in the Exponential diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:TIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:TIMe<value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the total time for the current or voltage to go from the starting level to the ending level in
seconds for Arb sequence steps.
Parameter Typical Return
0 – 262.144 | MIN | MAX, *RST 0 <total time>
Step 0 - 99, *RST 0 (none)
Programs the total time for the current Arb: ARB:CURR:EXP:TIM 10,(@1)
Programs the total time for the voltage Arb: ARB:VOLT:EXP:TIM 10,(@1)
Programs the total time for step 0: ARB:SEQ:STEP:CURR:EXP:TIM 10, 0,(@1)
7 SCPI Programming Reference
240 Keysight N6705C Operating and Service Guide
