[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:STARt[:LEVel] <value>, <step#>, (@<chanlist>)

[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:STARt[:LEVel]? [MIN|MAX,] <step#>, (@<chanlist>)

[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:STARt[:LEVel] <value>, <step#>, (@<chanlist>)

[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:STARt[:LEVel]? [MIN|MAX,] <step#>, (@<chanlist>)

Specifies the initial current or voltage before the ramp occurs for Arb sequence steps.

Parameter Typical Return

Current: 0 - maximum|MIN|MAX, *RST MIN

Voltage: 0 - maximum|MIN|MAX, *RST MIN

The maximum value varies, depending on the currentor voltage

rating of the power module.

Step 0 - 99, *RST 0 (none)

Programs a start level current: ARB:CURR:RAMP:STAR 1,(@1)

Programs a start level voltage: ARB:VOLT:RAMP:STAR 1,(@1)

Programs a start level for step 0: ARB:SEQ:STEP:CURR:RAMP:STAR 1, 0,(@1)

[SOURce:]ARB:CURRent:RAMP:STARt:TIMe <value>, (@<chanlist>)

[SOURce:]ARB:CURRent:RAMP:STARt:TIMe? [MIN|MAX,] (@<chanlist>)

[SOURce:]ARB:VOLTage:RAMP:STARt:TIMe<value>, (@<chanlist>)

[SOURce:]ARB:VOLTage:RAMP:STARt:TIMe? [MIN|MAX,] (@<chanlist>)

Specifies the delay in seconds after the trigger is received, but before the ramp occurs. Referenced to

t0 in the Ramp diagrams.

[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:STARt:TIMe <value>, <step#>, (@<chanlist>)

[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:STARt:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)

[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:STARt:TIMe<value>, <step#>, (@<chanlist>)

[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:STARt:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)

Specifies the delay in seconds after the trigger is received for Arb sequence steps.

Parameter Typical Return

0 – 262.144 | MIN | MAX, *RST 0 <start time>

Step 0 - 99, *RST 0 (none)

Programs a start time for the current ramp: ARB:CURR:RAMP:STAR:TIM 1,(@1)

Programs a start time for the voltage ramp: ARB:VOLT:RAMP:STAR:TIM 1,(@1)

Programs a start time for step 0: ARB:SEQ:STEP:CURR:RAMP:STAR:TIM 1, 0,(@1)

7 SCPI Programming Reference

246 Keysight N6705C Operating and Service Guide
