Keysight N9010B - Mask Standard

3 VMA Mode
3.9 SEM Measurement
Preset
STD
State Saved Saved in instrument state
Range
STD | MAN
Backwards
Compatibility
SCPI
[:SENSe]:SEMask:LIMits STD | MAN
Notes ON aliases to STD
OFF aliases to MAN
Range Auto | Man
Backwards Compatibility
SCPI
[:SENSe]:SEMask:T80Mask:AUTO ON | OFF | 1 | 0
[:SENSe]:SEMask:T80Mask:AUTO?
Mask Standard
Allows you to select various masks according to region-specific standards. Only
appears in WLAN Mode.
Mask
Selected
Example Mask used as auto standard mask
IEEE
:SEM:LIM:STAN
IEEE
Mask defined in IEEE 802.11-2012 standard
FCC Class A
:SEM:LIM:STAN
FCA
Mask defined in FCC 11p standard for STA transmit
power class A
FCC Class B
:SEM:LIM:STAN
FCB
Mask defined in FCC 11p standard for STA transmit
power class B
FCC Class C
:SEM:LIM:STAN
FCC
Mask defined in FCC 11p standard for STA transmit
power class C
FCC Class D
:SEM:LIM:STAN
FCD
Mask defined in FCC 11p standard for STA transmit
power class D
ETSI CCH
SCH1/5/6
:SEM:LIM:STAN
ESCH1
Mask defined in ETSI 11p standard for G5-CCH, G5-
SCH1,G5-SCH5 and G5-SCH6 channels
ETSI SCH2/3
:SEM:LIM:STAN
ESCH2
Mask defined in ETSI 11p standard for G5-SCH2 and G5-
SCH3 channels
ETSI SCH4
:SEM:LIM:STAN
ESCH4
Mask defined in ETSI 11p standard for G5-SCH4 channel
Remote Command
[:SENSe]:SEMask:LIMits:STANdard IEEE | FCA | FCB | FCC | FCD | ESCH1 |
ESCH2 | ESCH4
[:SENSe]:SEMask:LIMits:STANdard?
Example
:SEM:LIM:STAN IEEE
Dependencies Only available in WLAN Mode
Vector Modulation Analyzer Mode User's &Programmer's Reference 1480
