Keysight N9010B Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Max 65536
Remez
The following functions are available when this is the selected filter type.
Attenuation
Enables you to specify the stop-band attenuation of the filter in dB.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:REMez:ATTenuation <rel_ampl>
[:SENSe]:OFDM:CCARrier0|…|7:REMez:ATTenuation?
Example
:OFDM:CCAR0:REM:ATT -20dB
Preset -60
State Saved Saved in instrument state
Min -300dB
Max 0dB
Ripple
Enables you to specify the peak-to-peak ripple of the pass-band in dB.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:REMez:RIPPle <double>
[:SENSe]:OFDM:CCARrier0|…|7:REMez:RIPPle?
Example
:OFDM:CCAR0:REM:RIPP 0.1dB
Preset 0.1
State Saved Saved in instrument state
Min 0.0001dB
Max 20dB
Windowed Sinc
The following functions are available when this is the selected filter type.
Length
Enables you to specify the windowed sinc length (number of coefficients).
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:WSINc:LENGth <int>
[:SENSe]:OFDM:CCARrier0|…|7:WSINc:LENGth?
523 Vector Modulation Analyzer Mode User's &Programmer's Reference
