3 VMA Mode

3.9 SEM Measurement

3.9.20.5 Advanced

Contains controls for setting advanced trace functions of the instrument.

Measure Trace

Specifies which trace’s scalar results are displayed in the Metrics window, and

retrieved by sending a :READ or :FETCh query:

–

Trace 1

–

Trace 2

–

Trace 3

Remote Command

:CALCulate:<meas>:MTRace TRACe1 | TRACe2 | TRACe3

:CALCulate:<meas>:MTRace?

<meas> is the identifier for the current measurement; any one of CHPower | ACPower |

OBWidth | SEMask | SPURious | PVTime

Example Channel Power

:CALC:CHP:MTR TRAC1

:CALC:CHP:MTR?

Dependencies In the ACP measurement, this control is grayed-out when Meas Method is set to RBW or FAST, and

only Trace 1 is enabled

Preset

TRACe1

State Saved No

Range Trace 1 | Trace 2 | Trace 3

1603 Vector Modulation Analyzer Mode User's &Programmer's Reference
