3 VMA Mode
3.2 Custom OFDM Measurement
Measure Carrier
Specifies whether or not to measure this component carrier.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7[:STATe] OFF | ON | 0 | 1
[:SENSe]:OFDM:CCARrier0|…|7[:STATe]?
Example
:OFDM:CCAR0 ON
:OFDM:CCAR0?
Notes Used with a sub-op code <n> (default = 0) to specify the component carrier for configuration. The range
of the sub-op code is determined by the number of component carriers
Preset ON
State Saved Saved in instrument state
Range OFF|ON
Frequency Offset
Sets the component carrier center frequency as the offset from the "Carrier
Reference Frequency" on page 474.
Remote
Command
[:SENSe]:OFDM:CCARrier<n>:FREQuency:OFFSet <freq>
[:SENSe]:OFDM:CCARrier<n>:FREQuency:OFFSet?
Example
:OFDM:CCAR4:FREQ:OFFS 10MHz
:OFDM:CCAR4:FREQ:OFFS?
Notes Used with a sub-op code <n> (default = 0) to specify the component carrier for configuration. The range
of the sub-op code is determined by the number of component carriers
Preset 0Hz
State Saved Saved in instrument state
Min -100 GHz
Max 100 GHz
Bandwidth
Lets you set the bandwidth of each component carrier for the OFDM signal.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:BANDwidth <freq>
[:SENSe]:OFDM:CCARrier0|…|7:BANDwidth?
Example
:OFDM:CCAR4:BAND 80MHz
Preset 100 MHz
497 Vector Modulation Analyzer Mode User's &Programmer's Reference
