3 VMA Mode

3.2 Custom OFDM Measurement

Synchronization Search Offset

Sets the synchronization search offset (in symbols) used when synchronizing to the

signal.

Remote

Command

[:SENSe]:OFDM:CCARrier0|…|7:SYNChronize:SEARch:OFFSet <int>

[:SENSe]:OFDM:CCARrier0|…|7:SYNChronize:SEARch:OFFSet?

Example

:OFDM:CCAR0:SYNC:SEAR:OFFS 0

:OFDM:CCAR0:SYNC:SEAR:OFFS?

Preset 0

State Saved Saved in instrument state

Min 0

Max Depends on Max Result Length

Compensate Symbol Clock Error

Enables or disables the internal adjustment in the timing of the symbol clock.

Remote

Command

[:SENSe]:OFDM:CCARrier0|…|7:SYMBol:COMPensate:CERRor OFF | ON | 0 | 1

[:SENSe]:OFDM:CCARrier0|…|7:SYMBol:COMPensate:CERRor?

Example

:OFDM:CCAR0:SYMB:COMP:CERR 0

:OFDM:CCAR0:SYMB:COMP:CERR?

Preset OFF

State Saved Yes

Range Hex|Binary

EVM Normalized by Reference

Specifies EVM normalized to the IQ Reference signal power.

Remote

Command

[:SENSe]:OFDM:CCARrier0|…|7:EVMNorm OFF | ON | 0 | 1

[:SENSe]:OFDM:CCARrier0|…|7:EVMNorm?

Example

:OFDM:CCAR0:EVMN 1

:OFDM:CCAR0:EVMN?

Preset ON

State Saved Yes

Vector Modulation Analyzer Mode User's &Programmer's Reference 528
