CONFigure:{RESistance|FRESistance} [{<range>|AUTO|MIN|MAX|DEF} [, {<resolution>|MIN|MAX|DEF}]]
Sets all measurement parameters and trigger parameters to their default values for 4-wire (FRESistance)
or 2-wire (RESistance) resistance measurements. Also specifies the range and resolution.
Parameter Typical Return
<range>: 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1 MΩ, 10 MΩ, 100 MΩ, 1
GΩ, AUTO,or DEFault. Default: AUTO.
+8.54530000E+01
<resolution>: See Resolution Table or Range, Resolution and
NPLC. The default is equivalent to 10 PLC.
Specify <resolution> in the measurement's units (V, A, Hz, Ω, and
so on).
Configure 4-wire resistance measurements using the 100 Ω range with default resolution. Make and read
two measurements:
CONF:FRES 100
SAMP:COUN 2
READ?
Typical Response: +8.54530000E+01,+8.54520000E+01
l The 1 GΩ range applies only to the 34465A and 34470A.
l You can let autoranging select the measurement range, or you can manually select a fixed range.
Autoranging conveniently selects the range for each measurement based on the input signal. For fast-
est measurements, use manual ranging (autoranging may require additional time for range selection).
l
Autoranging (AUTO or DEFault), will generate an error if you specify a <resolution> because the instru-
ment cannot accurately resolve the integration time (especially if the input continuously changes). If
your application requires autoranging, specify DEFault for the <resolution> or omit the <resolution>
altogether.
l Autoranging goes down a range at less than 10% of range and up a range at greater than 120% of
range.
l If the input signal is greater than can be measured on the specified manual range, the instrument dis-
plays the word Overload on front panel and returns "9.9E37" from the remote interface.
l Use READ? or INITiate to start the measurement.
See Also
CONFigure?
MEASure:{RESistance|FRESistance}?
SCPI Programming Reference
250
Keysight Truevolt Series Operating and Service Guide
