Stratos Multi E401N
139
pH, ORP
Error no. Type Message text Notes/solution
P001 Configuration Data
Loss
Data error in the configuration:
Fully reconfigure the device.
P008 Adjustment Data Error in the adjustment data:
Switch device off (approx. 10 s).
If the message persists, send in the device.
P009 Firmware Error Error in the firmware:
Switch device off (approx. 10 s).
Reload the firmware. ➜
Firmware Update (FW-E106), p. 213
If the message persists, send in the device.
P010 pH Range Measuring range exceeded. Possible causes: Sensor not or incorrectly con-
nected, sensor faulty, cable faulty, incorrect temperature probe selected,
temperature probe faulty.
With MK-PH015 module without connection to solution ground: No jumper
between terminals B and C. ➜
pH Analog Wiring Examples, p. 168
P011 pH LO_LO Value below configured monitoring limit
P012 pH LO Value below configured monitoring limit
P013 pH HI Value above configured monitoring limit
P014 pH HI_HI Value above configured monitoring limit
P015 Temperature Range Measuring range exceeded. Possible causes: Sensor not or incorrectly
connected, cable faulty, incorrect temperature probe selected.
P016 Temperature LO_LO Value below configured monitoring limit
P017 Temperature LO Value below configured monitoring limit
P018 Temperature HI Value above configured monitoring limit
P019 Temperature HI_HI Value above configured monitoring limit
P020 ORP Range Measuring range exceeded. Possible causes: no ORP sensor connected, sen-
sor incorrectly connected, sensor faulty, cable faulty.
On pH measurement with MK-PH015 module: MK-PH: No jumper between
terminals B and C. ➜
pH Analog Wiring Examples, p. 168
P021 ORP LO_LO Value below configured monitoring limit
P022 ORP LO Value below configured monitoring limit
P023 ORP HI Value above configured monitoring limit
P024 ORP HI_HI Value above configured monitoring limit
P025 rH Range Measuring range exceeded. Possible causes: no pH/ORP combo sensor
connected, sensor incorrectly connected, cable faulty.
P026 rH LO_LO Value below configured monitoring limit
P027 rH LO Value below configured monitoring limit
P028 rH HI Value above configured monitoring limit
P029 rH HI_HI Value above configured monitoring limit
P045 pH Voltage Range Measuring range exceeded. Possible causes: Sensor not or incorrectly
connected, sensor faulty, cable faulty.
P046 pH Voltage LO_LO Value below configured monitoring limit
P047 pH Voltage LO Value below configured monitoring limit
P048 pH Voltage HI Value above configured monitoring limit
