Knick Stratos Multi E401N - Page 170

Stratos Multi E401N
170
Example 3, pH Analog
Measuring task: pH, temp, glass impedance
Sensor: pH sensor e.g., SE 554X/1-NVPN, cable CA/VP6ST-003A
Temperature probe: Integrated
B C D E F G H
A I K
meas. el ref. el. SG +3 V –3 V ISM (GND) ISM (Data) RTD (GND) RTD shield
1 2 4 5
3
6
7
8
9
1
Core, clear
6
Shield, yellow/green
2
Shield, red
7
pH Module
3
Jumper!
8
VP cable
4
Green
9
Sensor
5
White
