Example 5, pH Analog
Measuring task: pH/ORP, temp., glass impedance, reference impedance
Sensors (example): PL PETR-120VP (pH/ORP combo sensor, SI Analytics)
Cable (example): CA/VP6ST-003A
B C D E F G H
A I K
meas. el ref. el. SG +3 V –3 V ISM (GND) ISM (Data) RTD (GND) RTD shield
1 2 4 53 6
7
8
9
1
Core, transparent
6
Shield, yellow/green
2
Shield, red
7
pH Module
3
Blue
8
Cables
4
Green
9
Sensor
5
White
