Knick Stratos Multi E401N - Page 178

Stratos Multi E401N
178
Example 4, Cond
Measuring task: Conductivity, temperature
Sensors (example): 2-electrode sensor SE610
B C D E F G H
A
I hi U hi U lo I lo RTD RTD (sense) RTD (GND) shield
1
2 3 4 5
6
11
7
8
1
Jumper!
5
Yellow
2
Brown
6
Cond Module
3
White
7
Fixed cable
4
Green
8
Sensors
