Knick Stratos Multi E401N - Page 177

Stratos Multi E401N
177
Example 3, Cond
Measuring task: Conductivity, temperature
Sensors (example): 2-electrode sensor, SE604, cable ZU0645
B C D E F G H
A
I hi U hi U lo I lo RTD RTD (sense) RTD (GND) shield
1 4 3 6
A
5 2
A
1
2
3
4
5
6
1
2 3 4 5 6 7 8 9
10
11
12
13
1
White
8
Red
2
Pink
9
Black, shield
3
Brown
10
Cond Module
4
Gray
11
Cables
5
Blue
12
Sensors
6
Green
13
Sensor head connector
7
Yellow
