8
2.1–2c: Octave, Transpose, Tune, Delay
Octave [–2[32’], –1[16’], +0[8’], +1[4’]]
Adjusts the pitch in octave units. The normal octave of the
multisample is 8' (feet).
Transpose [–12…+12]
Adjusts the pitch in semitone steps over a range of ±1
octave.
Tune [–1200…+1200]
Adjusts the pitch of the sample in one-cent steps (a semitone
is 100 cents) over a range of ±1 octave.
Delay [0ms…5000ms, KeyOff]
Specifies a delay time from note-on until the note will
sound.
With a setting of KeyOff, the sound will begin when note-off
occurs. This is used to create sounds such as the “click” that is
heard when a harpsichord note is released. In this case, set the
“Amp1 EG”, “Amp2 EG” (5.1–3a, 5.2–3) “S (Sustain Level)”
parameter to 0.
2.1–2d: OSC1 Drum Kit
Drum Kit [00(I-A/B)...143(E-H), 144(GM)...152(GM)]
Selects a drum kit.
Octave [–2[32’], –1[16’], +0[8’], +1[4’]]
Adjusts the pitch in octave units. When using a drum kit, set
the Octave to 8'.
When editing a drum program, you must set this
parameter to 8'. With other settings, the sounds of the
drum kit will be assigned to the wrong notes of the key-
board.
Transpose [–12…+12]
This adjusts the location of the instruments in the selected
drum kit. Unless you need to change this, leave it at 0.
Tune [–1200…+1200]
This adjusts the pitch in one-cent units.
The pitch of each drum kit can be adjusted in GLOB 5.1:
DKit.
Delay [0ms…5000ms, KeyOff]
This specifies a delay time from note-on until the sound will
begin.
With a setting of KeyOff, the sound will begin when note-
off occurs. In this case, set the “Amp1 EG” parameter “S
(Sustain Level)” (5.1–3a) to 0.
■ 2.1–2e. UTILITY
☞ “Write Program” (1.1–1d), “Copy Oscillator,” “Swap
Oscillator” (2.1–1d)
For details on how to select the desired utility function, refer
to “PROG 1.1–1d: UTILITY.”
Select by Category
Selects multisamples by category.
For the procedure, refer to “Select by Category” (
☞p.2).
This command is valid if “Mode (Oscillator Mode)”
(2.1–1a) is Single or Double, and you are selecting the
“High MS Bank,” “High Multisample,” “Low MS
Bank,” or “Low Multisample” of OSC1 or OSC2 for
which ROM was selected for “High MS Bank” or “Low
MS Bank.”
Sample Parameters
This command lets you adjust the sample playback level,
cutoff, resonance, pitch, attack, and decay for each index of a
RAM multisample.
This command is valid if “Mode (Oscillator Mode)”
(2.1–1a) is Single or Double, and you are selecting the
“High MS Bank,” “High Multisample,” “Low MS
Bank,” or “Low Multisample” of OSC1 or OSC2 for
which RAM was selected for “High MS Bank” or “Low
MS Bank.”
The setting will apply to the selected multisample. The
setting will also be used when that multisample is
selected by another oscillator or program.
1 Select “Sample Parameters” to access the dialog box.
2 Index: Specifies the index for which you wish to make
settings. The number following “/” is the total number of
indexes in the selected multisample.
SMPL: Indicates the sample number and name for the
index.
3 For each index, you can make the following settings.
Level: Adjusts the volume. Relative to the settings of
“Level (High, Low Level)” (2.1–2b) and “Level (Amp1, 2
Level)” (5.1–1a, 5.2–1), negative (–) values will decrease
the levels, and positive (+) values will increase the levels.
A setting of +99 will double the volume, and at a setting
of –99 there will be no sound. This parameter is linked to
the “Level” (SMPL 4.1–2a). The value that was specified
in Sampling mode will be displayed here.
Cutoff: Adjusts the filter cutoff. This adjustment will be
added to the value specified for “Frequency” (4.1–1b/1c,
4.2–1) of Filter 1 and 2.
Resonance: Adjusts the resonance level of the filter. This
adjustment will be added to the value specified for “Res-
onance” (4.1–1b, 4.2–1) of Filter 1 and 2.
Pitch: Adjusts the playback pitch in one-cent steps. A set-
ting of +12.00 raises the pitch one octave, and a setting of
–12.00 will lower the pitch one octave. This parameter is
linked with the parameter “Pitch” (SMPL 4.1–2a). The
value that was specified in Sampling mode will be dis-
played here.
Attack: Adjust sthe attack times of the filter EG and amp
EG. This adjustment will be added to the “A (Attack
Time)” of “Filter 1 EG,” “Filter 2 EG,” “Amp 1 EG,” and
“Amp 2 EG” (4.1–5a, 4.2–5, 5.1–3a, 5.2–3).
00(I-A/B)–15(I-A/B): Preloaded Drum kits.
16(E-A)–31(E-A), 32(E-B)–47(E-B), 48(E-C)–63(E-C), 64(E-D)–
79(E-C), 80(E-E)–95(E-E), 96(E-F)–111(E-F), 112(E-G)–127(E-G),
128(E-H)–143(E-H):
(for user drum kits, EXB-PCM series drum kits)
144(GM)–152(GM): Preset drum kits compatible with GM2.
