Appendices
213
When “BPM” is set to MIDI, the effect will synchronize to
the tempo of the arpeggiator or the RPPR (or to an external
MIDI clock). If “BPM” is in the range of 40–240, the specified
value will be used.
If the tempo, “Bs (Base Note),” and “Times” settings in con-
junction would cause the maximum delay time to be
exceeded, a warning such as “TimeOver? >OVER!” will
appear in the display. Please modify your settings so that
this setting does not appear. (The maximum delay time will
depend on the effect type.)
The following functions can be assigned to “SW1” and
“SW2.” These functions can be controlled by pressing the
“SW1” or “SW2” buttons (F6, F7 keys) in the pages of each
mode that allow such operations.
• For a program, combination, or multi, make the settings
in 2.2: Ed-Ctrl/Controller page “SW1/2 Assign” (2.2–
1b).
• In Sampling mode, make the settings in 5.2: Controls
page “SW1/2 Assign” (5.2–1b).
SW1, SW2 Assign List
* These values can be specified, but will have no actual
effect. N/A indicates Not Available (i.e., invalid).
Data compatibility is maintained between the TRITON-
Rack and the TRITON/TRITONpro/TRITONproX (TRI-
TON keyboard models). Programs created on the TRI-
TON-Rack can be used on TRITON keyboard models,
and the opposite is also true.
In order to maintain compatibility, it is possible to specify
these “invalid” parameters on the TRITON-Rack.
SW1 Mod.(CC#80) (SW1 Modulation:CC#80)
SW2 Mod.(CC#81) (SW2 Modulation:CC#81)
This effect differs between SW1 and SW2. SW1 is handled as
CC#80, and SW2 is handled as CC#81.
Porta.SW(CC#65) (Portamento Switch:CC#65)
When PROG 2.1: Ed–Basic “Mode (Oscillator Mode)” (2.1–
1a) is Single, turning the switch on (LED lit) will apply por-
tamento regardless of the 3.1: Ed–Pitch “Enable (Porta.
Enable)” (3.1–1c) setting, and turning the switch off will not
apply portamento.
If “Mode (Oscillator Mode)” is Double, and if the “Enable
(Porta. Enable)” setting is the same for OSC1 and 2 (i.e.,
Enable or Disable for both OSC1 and 2), then portamento
will be applied to OSC1 and 2 when the switch is turned on ,
and portamento will not be applied to OSC1 and 2 when the
switch is turned off.
If the “Enable (Porta. Enable)” setting is different for OSC1
and 2 (i.e., OSC1 is Enable and OSC2 is Disable, or OSC1 is
Disable and OSC2 is Enable), then portamento will be
applied to the OSC whose setting is Enable when the switch
is turned on, and portamento will be applied to neither OSC
when the switch is turned off.
SW1/2 Assign
Off no function
SW1 Mod.(CC#80) (SW1 Modulation:CC#80)
SW2 Mod.(CC#81) (SW2 Modulation:CC#81)
Select this when using the switch as an Alternate Modulation or Effect Dynamic Modulation
source. In this case, you must first specify the control destination. Each time the switch is turned
On/Off, a CC#80 (or CC#81) message will be transmitted (Off: 0, On: 127). (☞p.213)
Porta.SW(CC#65) (Portamento Switch:CC#65) When you press SW1 (or SW2) to turn it on (LED lit), portamento will be applied. Each time this is
turned On/Off, CC#65 will be transmitted (Off: 0, On: 127). (☞p.213)
Octave Down :N/A * —
Octave Up :N/A * —
JS X Lock :N/A * —
JS+Y Lock :N/A * —
JS-Y Lock :N/A * —
Ribbon Lock :N/A * —
JS X&Rbn Lock :N/A * —
JS+Y&Rbn Lock :N/A * —
JS-Y&Rbn Lock :N/A * —
AfterT Lock :N/A * —
