The following table shows the operations that the TRITON-
Rack will perform when control change messages are
received, and the relation between settings and controller
movements on the TRITON-Rack
TRITON-Rack operations
when control changes are
transmitted/received
CC# Control Value Function
0 Bank select (MSB) 0...127 bank select message MSB *1
1 Modulation 1 0...127 Controls modulation (normally the vibrato effect), Alternate Modulation
(corresponds to AMS: JS+Y#01), or Effect Dynamic Modulation (corresponds
to Dmod Src: JS+Y#1)
2 Modulation 2 0...127 Controls modulation (normally the wah effect), Alternate Modulation
(corresponds to AMS: JS+Y#02), or Effect Dynamic Modulation (corresponds
to Dmod Src: JS+Y#2)
4 Foot controller 0...127 Controls Alternate Modulation (corresponds to AMS: Pedal #4) or Effect
Dynamic Modulation (corresponds to Dmod Src: Pdl#4)
5 Portamento time 0...127 portamento time
6 Data entry (MSB) 0...127 MSB of RPN and NRPN data *2
7 Volume 0...127 volume *3
8 Post insertion effect panpot 0...127 pan after the insertion effect
10 Panpot 0...127 pan
11 Expression 0...127 volume *3
12 Effect control 1 0...127 Controls Effect Dynamic Modulation (corresponds to Dmod Src: FX1#12)
13 Effect control 2 0...127 Controls Effect Dynamic Modulation (corresponds to Dmod Src: FX2#13)
16 Controller (CC#16) 0...127 Controls modulation, Alternate Modulation (corresponds to AMS: Ribbon
#16), or Effect Dynamic Modulation (corresponds to Dmod Src:Rbn#16)
17 Knob modulation 1 0...127 corresponds to when Knob Mod.1 is assigned as the B-mode function
of a REALTIME CONTROLS knob
18 Controller (CC#18) 0...127 Controls Alternate Modulation (corresponds to AMS: Slider #18) or Effect
Dynamic Modulation (corresponds to Dmod Src:Sld#18)
19 Knob modulation 2 0...127 corresponds to when Knob Mod.2 is assigned as the B-mode function
of a REALTIME CONTROLS knob
20 Knob modulation 3 0...127 corresponds to when Knob Mod.3 is assigned as the B-mode function
of a REALTIME CONTROLS knob
21 Knob modulation 4 0...127 corresponds to when Knob Mod.4 is assigned as the B-mode function
of a REALTIME CONTROLS knob
32 Bank select (LSB) 0...127 LSB of bank select message *1
38 Data entry (LSB) 0...127 LSB of RPN or NRPN data *2
64 Damper 0...127 damper effect
65 Portamento On/Off 0...63(Off), 64...127(On) turn the portamento effect on/off
66 Sostenuto On/Off 0...63(Off), 64...127(On) turn the sostenuto effect on/off
67 Soft 0...127 soft pedal effect
70 Sustain level 0...127 sustain levels of the filter EG and amp EG *4
71 Filter resonance level
High pass filter cutoff frequency
0...127
0...127
resonance level of the filter
cutoff frequency of the high pass filter
*5
*4
72 Release time 0...127 release times of the filter EG and amp EG *4
73 Attack time 0...127 attack times of the filter EG and amp EG *4
74 Low pass filter cutoff frequency 0...127 cutoff frequency of the low pass filter *4
75 Decay time 0...127 decay times/slope times of the filter EG and amp EG *4
76 LFO1 speed 0...127 LFO1 speed *4
77 LFO1 depth 0...127 pitch LFO1 intensity *4
78 LFO1 delay 0...127 LFO1 delay *4
79 Filter EG intensity 0...127 filter EG intensity *4
80 Panel switch 1 On/Off 0...63(Off), 64...127(On) corresponds to on/off when the SW1 function is set to SW1 Mod.
81 Panel switch 2 On/Off 0...63(Off), 64...127(On) corresponds to on/off when the SW2 function is set to SW2 Mod.
82 Foot switch On/Off 0...63(Off), 64...127(On) Controls Alternate Modulation (corresponds to AMS: FootSW #82) or Effect
Dynamic Modulation (corresponds to Dmod Src: FSW#82)
83 Controller (CC#83) 0...127 Controls Alternate Modulation (corresponds to AMS: MIDI CC#83) or Effect
Dynamic Modulation (corresponds to Dmod Src: CC#83)
91 Effect 1 depth 0...127 send 2 level
92 Effect 2 depth 0(Off), 1...127(On) turn insertion effect 1, 2, 3, 4, 5 on/off *6
93 Effect 3 depth 0...127 send 1 level
94 Effect 4 depth 0(Off), 1...127(On) master effect 1 on/off *6
95 Effect 5 depth 0(Off), 1...127(On) master effect 2 on/off *6
96 Data increment 0
97 Data decrement 0
98 NRPN(LSB) 2
10
11
Corresponds to the arpeggiator on/off switch
Corresponds to the arpeggiator gate control (REALTIME CONTROLS
knob 2 C-mode)
Corresponds to the arpeggiator velocity control (REALTIME CONTROLS
knob 3 C-mode)
*7
*7
*7
99 NRPN(MSB) 0 MSB of NRPN
100 RPN(LSB) 0 select the pitch bend range *2
1 select Fine Tune *2
2 select Coarse Tune *2
101 RPN(MSB) 0 MSB of RPN
