10 TUNING THE CHASSIS 151
B01404-10
–
Remove screws

and take off the shift rod.
–
Loosen lock nuts

.
– Adjust the shift rod.
Guideline
Shift rod adjustment range 114… 153 mm (4.49… 6.02 in)
Info
Make the same adjustments on both sides.
At least 5 screw threads must be screwed into the seating.
